57 EKI-1526(TI) | 1528(TI) User Manual
Pack conditions (Pack sent immediately when reach 1024 Bytes)
By size Click the option to send pack immediately by size.
By interval Click the option to send pack immediately by interval.
By end-character Click the option to send pack immediately by end-character.
Port Data Buffering
Port Data Buffering Click the drop-down menu to select port data buffering type: None or
RAM.
When Data Full Click the drop-down menu to select process mode when data full:
Stop.
USDG Data Mode
Protocol Click the drop-down menu to select the protocol: TCP or UDP.
Data Idle Timeout (s) Enter a value to define the data idle timeout period.
Data Listen Port Enter a value to identify the channel for remote initiating connections.
Command Listen
Port
Enter a value to identify the command listen port for accepting con-
nected request of other network device.
Response Timeout
(ms)
Enter a value to define the response timeout period.
Frame Break (ms) Enter a value to specify the frame break time.
TCP Mode Extra Options
Auto Connect To
Peer IP
Click the option to connect to TCP/IP which are set at Peers page
automatically after boot up.
Port Data Buffering
Media Click the drop-down menu to select port data buffering type: None or
RAM.
When Data Full Click the drop-down menu to select process mode when data full:
Stop.
Pack conditions (Pack sent immediately when reach 1024 Bytes)
By size Click the option to sent pack immediately by size.
By interval Click the option to sent pack immediately by interval.
By end-character Click the option to sent pack immediately by end-character.
By character-timeout Click the option to sent pack immediately by character-timeout.
Peer for Receiving Data
Peer Number Click the drop-down menu to select the number of network device
which you want to connect. Maximum is 16 network devices.
USDG Control Mode
Protocol Display the current protocol of the USDG control mode.
Data Idle Timeout (s) Enter a value to define the data idle timeout period.
Data Listen Port Enter a value to identify the channel for remote initiating connections.
Command Listen
Port
Enter a value to identify the command listen port for accepting con-
nected request of other network device.
Hang up Character The default character is “+”. After you have connected to another
serial device via an EKI device, you may need to disconnect, using
the command “+++”. To do this, press “+” three times and wait for the
idle timeout <default value is 100ms>; the device will disconnect. You
can set “Guard Time” to define the idle time.
Guard Time (ms) Enter a value to identify the guard time.
RFC2217 Mode
Listen Port Enter a value to identify the channel for remote initiating connections.
Item Description
