• To
prevent mechanical or electrical damage, do not keep an electrical component on for a long time.
1. Select SP 5804.
2. Select the number (see the table below) corresponding to the component.
3. Select "ON."
4. To stop the operation, select "OFF."
- Output Check Table -
Number 005, 006, 040, and 041 may not respond when the fusing temperature is high.
Num. Component
001 Main Motor Forward
002 Main Motor Reverse
003 Quenching Lamp
004 Toner Supply Motor Forward
005 Fan Motor High
006 Fan Motor Low
007 Registration Clutch
008 By-pass Feed Clutch
009 Upper Feed Clutch
010 Lower Feed Clutch
011 BK-Low Lift Motor Up
012 BK-Low Lift Motor Down
013 Relay Clutch
014 BK-Relay Clutch
015 BK-Upper Feed Clutch
016 BK-Lower Feed Clutch
017 BK-Lift Motor
018 BK-Up Lift Motor Up
5. Service Tables
110
