Test Patterns Using SBU
52 Gray scale 1 (256 grades)
53 Gray scale 2 (256 grades)
Paper Jam Counters (SP 7504)
The table lists the menu numbers (the last three digits of SP 7504 XXX) and the paper jam timings and
locations.
Code
001 Paper jam occurs at power on.
010 Paper does not reach the registration sensor (from a paper tray).
050 Paper does not reach the registration sensor (from the by-pass tray).
070 Paper is caught at the registration sensor.
120 Paper is caught at the exit sensor (previous page).
121 Paper does not reach the exit sensor.
122 Paper is caught at the exit sensor.
SMC Print (SP 5990)
SP 5990 outputs machine status lists.
1.
Select SP 5990.
2. Select a menu:
001 All, 002 SP, 003 UP, 004 Log, or 005 Big Font
The output given by the menu "Big Font" is suitable for faxing.
3. Press the "Execute" key.
The copy mode is activated
Specify copy settings and press the key. The machine status lists is output.
4. To return to the SP mode, press the key.
5. Service Tables
