Aficio MP1900 - LD Unit

3. Pull out the (upper) paper tray.
4. Front cover
5. Laser unit [A] ( x 2, x 4)
• The screw at the left front position [B] is longer than the other three.
LD Unit
• Do not touch the paint-locked screw [A]. The LD position is adjusted before shipment.
1. Laser unit
2.
LD unit [B] (
x 1)
• Do not screw the LD unit in too tightly when you install it.
Laser Unit
59
4
