Aficio MP1900 - BICU (Base-Engine Image Control Unit)

BICU (Base-Engine Image Control Unit)
1. Rear cover
2.
BICU [A] (
x 7, all connectors, 2 flat cables)
• Remove
the NVRAM [B] from the old BICU and install it on the new BICU when you replace the
BICU. The NVRAM keeps machine-specific data.
Other Replacements
89
4
