Aficio MP1900 - Other Replacements; Quenching Lamp; High-Voltage Power Supply Board

Other Replacements
Quenching Lamp
1. PCU
2.
Quenching lamp [A] (
x 1)
High-Voltage Power Supply Board
1. Rear cover
2. High-voltage power supply board [A] ( x 2, 3 standoffs, all connectors)
4. Replacement and Adjustment
88
4
