Aficio MP1900 - Toner Supply Motor; Pick-Off Pawls and Toner Density Sensor

Toner Supply Motor
1. Copy tray ( p.43 "Upper Covers")
2.
Open the front door.
3. Toner bottle holder (
p.63 "PCU")
4.
Toner supply motor [A] (
x 1)
Pick-off Pawls and Toner Density Sensor
• Do not turn the PCU upside down. This causes toner and developer to spill out.
4. Replacement and Adjustment
64
4
