Copier Installation
Power Sockets for Peripherals
• Make sure to plug the cables into the correct sockets.
[A]: Socket for ADF (Rated voltage output max. DC24 V)
[B]: Socket for paper tray unit (Rated voltage output max. DC24 V)
Accessory Check
Check that you have the accessories in this list.
No. Description Q’ty
1 Multi-language (-17, -27,-19, -29) 1
2 NECR-English (-17) 1
3 Model Name Plate (-22, -19, -29) 1
4 Operating Instruction (-17, -19, -29) 1
2. Installation
20
