Aficio MP1900 - Appendix: SP Mode Tables; SP1-XXX (Feed)

4. Appendix: SP Mode Tables
SP Mode Tables
The following codes are used:
• Asterisk (*):
The settings are saved in the NVRAM. Most of them return to the default values when you
execute SP 5801 2
• The DFU menu is for design or factory use only. You must not change the settings.
• Brackets ([ ]): The brackets enclose the setting rage, default value, and minimum step (with unit) as
follows: [Minimum to Maximum / Default / Step].
• SSP: The program is in the SSP Mode only. Consult your supervisor before you use this program.
SP1-XXX (Feed)
1001*
Leading Edge Registration
Adjusts the printing leading-edge registration from paper trays.
1001 1 All Trays
[–9.0 to 9.0 / 0.0 / 0.1 mm/step] ( Copy
Adjustments Printing/Scanning)
1001 2 By-pass
1002*
Side-to-Side Registration
Adjusts the printing side-to-side registration from each paper feed station, using the
Trimming Area Pattern (SP 5902, No.10). Adjustments are supported for all 4 possible
feed trays (including optional trays).
The SP 1002 1 setting is applied to all trays, not just the 1st tray. Settings for trays 2 to 4
are offsets relative to the SP 1002 1 setting.
For duplex copies, the value for the front side is determined by SP 1002 1 to 4, and the
value for the rear side is determined by SP 1002 6.
1002 1 1st tray
[–9.0 to 9.0 / 0.0 / 0.1 mm/step] ( Copy
Adjustments Printing/Scanning)
1002 5 By-pass
1003*
Paper Feed Timing
Adjusts the amount of buckle the paper feed clutch applies to the paper after the registration
sensor is activated. A higher setting applies greater buckling.
29
4
