Aficio MP1900 - Drive Layout

1. Original Feed from ADF
2. Paper Feed from Tray 1
3. Paper Feed from By-pass Tray
Drive Layout
1. Scanner Motor
2. Main Motor
3. Hot Roller
4. OPC Drum
5. Development Roller
6. By-pass Feed Clutch
7. Paper Feed Clutch
8. Registration Clutch
1. Product Information
16
1
