Aficio MP1900 - Front Right Cover; Right Rear Cover

Front Right Cover
1. Open the front door [A].
2.
Front right cover [B] (
x 1)
Right Rear Cover
1. Right upper cover ( p.43 "Upper Covers")
2. Open the right door.
3. Right rear cover [A] ( x 1)
Exterior Covers & Operation Panel
45
4
