10. Gear [F] and bushing [G] ( x 1)
11. Registration roller [H] with the image transfer unit [I]
By-Pass Paper Size Switch
1. By-pass tray
2.
Tray lever [A] (
x 1, 1 pin)
3.
Lift the upper tray [B]
4. By-pass paper size switch [C] (
x 1)
• When reinstalling the switch: Move the paper guides to their middle position (about halfway
between
fully open and fully closed), and install the round gear so that the hole in the gear [D]
aligns with the peg [E] on the sliding gear.
4. Replacement and Adjustment
76
