EM 60k 120k AN NOTE
Cleaning blade (OPC drum) R
Pick-off pawls (OPC drum) R
Transfer roller R
ID sensor C C Blower brush
Paper Feed
EM 60k 120k AN NOTE
Paper feed roller C R C Clean with water or alcohol.
Friction pad C R C Clean with water or alcohol.
Bottom-plate pad C C Clean with water or alcohol.
Paper feed roller (by-pass tray) C C Clean with water or alcohol.
Friction pad (by-pass tray) C C Clean with water or alcohol.
Bottom-plate pad (by-pass tray) C C Clean with water or alcohol.
Registration rollers C C Clean with water or alcohol.
Paper feed guides C C Clean with water or alcohol.
Paper-dust Mylar C C Clean with water or alcohol.
Fusing Unit
EM 60k 120k AN NOTE
Hot roller R
Pressure roller R
Pressure roller cleaning roller R
Hot roller bushings I
Pressure-roller bushing R
Hot roller stripper pawls R C Dry cloth
Thermistor C C Dry cloth
2. Appendix: Preventive Maintenance
16
