132 1100 Series DAD and MWD User Manual
8Maintenance
2
After replacing the outlet capillary, fix it handtight first.
Then do a 1/4 turn with a 4-mm wrench.
3 To replace the inlet capillary, use a 4-mm wrench for the
fitting.
Video: Unscrew the cell body from the heat
exchanger and the heat exchanger
from the clamp unit.
4 Unscrew the fixing screw and unwrap the inlet capillary
from the grove in the flow cell body.
Outlet
Screw
Inlet capillary
with heat
exchanger
