Chapter 4 Angular Measurements
Angular Position Measurements
4-34 Measurements Reference Guide
Additional Notes:
G01 or G1 = Interpolate linearly—requires feed rate value
Fxx = Feed rate
Figure 4-18. Machine control program
O103;
/ Program ID (name or number)
•
•
•
G01F10000.;
/ Degrees per minute. See “Additional Notes,” below.
•
•
B30.0;
/ Rotate B axis 30 Degrees
•
G91G1F2000.Z-
3.0;
/ Move Z axis incrementally to engage Agilent 55290A or 55290B
fixture and precision index table in measurement position. See
“Additional Notes,” below.
•
•
G04P2000.;
/ Dwell 2.0 seconds
•
•
M08;
/ Any “M” function to trigger laser reading when available. (M08 =
coolant “on”)
M09;
/ Coolant “off”
G91G0Z3.0
/ Move Z axis incrementally to clear for B-axis rotation
M99;
/ Return to beginning
%
