Chapter 4 Angular Measurements
Angular Position Measurements
Measurements Reference Guide 4-63
Running the machine control program
After your program has passed your manual operation check, run it
automatically. While you are doing this, you can also check to be sure you
have set the Agilent 5530 calibrator to record data at the appropriate
times. Be sure your program has enough dwell time for the Agilent 5530
to record an appropriate value.
Making the measurement
In this procedure, you make automatic measurements as you rotate the
precision index table’s base. If you are using sensors, make sure they are
properly placed and the software is set up correctly. (Refer to the
Agilent 5530 Getting Started Guide for complete instructions on using the
software and the sensors.)
This section explains how to make measurements using the Record button
in the software and the optional remote control unit. See Chapter 1,
“Planning Your Measurements,” for a description of other triggering
methods.
To make the measurement, follow these steps:
1 Perform one measurement cycle, to place the measurement optic at its
start position.
2 On the Set Up Laser: ANGULAR window, select Set Up Meas.
The Set Up Measurement: ANGULAR screen is displayed (Figure 4-31).
