Chapter 6 Squareness Measurements in a Horizontal Plane
Checking the Alignment for Beam Strength for the Second Axis
Measurement
Measurements Reference Guide 6-27
Checking the Alignment for Beam Strength
for the Second Axis Measurement
Follow the instructions in “Checking the Alignment for Beam Strength” in
Chapter 5. Remember, do not move or adjust the reflector.
You are now ready to make the second axis measurement.
Making the Second Axis Measurement
To make the second axis measurement, follow these steps:
1 On the Set Up Laser: SQUARENESS screen, select the second axis you
are measuring.
2 Repeats steps 3 through 10 in “Making the First Axis Measurement.”
After you record the last measurement, the Analyze Data: SQUARENESS
screen is displayed (Figure 6-11).
Refer to the Agilent 5530 Getting Started Guide and online help for more
information about using this screen.
3 On the Analyze Data: SQUARENESS screen, select Save Data to create or
update a data file with the measurement data.
Otherwise, you are finished making the measurement.
