Chapter 4 Angular Measurements
Setting Up for a Pitch or Yaw Measurement
4-4 Measurements Reference Guide
Setting Up for a Pitch or Yaw Measurement
If you have not already done so, perform the following setup procedures
before using the rest of the instructions in this chapter. Refer to the
Agilent 5530 Getting Started Guide for complete instructions when
installing and starting the system for the first time.
1 Mount the laser head on the tripod and place the tripod near the target
machine.
2 Connect the E1735A USB Axis Module and the E1736A USB Sensor Hub
to the USB connectors on your PC. Connect the laser head and remote
control unit to the axis module. Connect the sensors to the sensor hub.
3 Plug in and turn on all equipment.
4 Start the Agilent 10747F Metrology Software.
The Metrology Main Menu is displayed.
5 On the Metrology Main Menu, select Angular.
The Set Up Laser: ANGULAR screen (Figure 4-2) is displayed.
Alternately, you can open an existing angular measurement setup file
from your database by selecting Recall Data on the Main Menu.
To Next Page
