Chapter 7 Squareness Measurements in a Vertical Plane
Setting Up for the Measurement
Measurements Reference Guide 7-5
Figure 7-2. Other Measurements screen
6 On the Other Measurements screen, select Squareness.
The Set Up Laser: SQUARENESS screen is displayed (Figure 7-3).
7 Complete the fields on the Set Up Laser: SQUARENESS screen.
If necessary, use the online help.
You are now ready to position the laser head and target machine.
