Introduction 1
Hardware Description
Operation Manual 15
Hardware Description
Figure 1 is an overview of a typical Agilent 7200 Accurate-Mass
Q-TOF GC/MS system.
Figure 1 7200 Q-TOF GC/MS System
Flight tube
ALS tray
Q-TOF
ALS
7890 GC
MS power
switch
Lower RIS
cover
Upper RIS
cover
GC power
switch
Tray
Oven door
latch
