Installing GC Columns 2

To Prepare a Capillary Column for Installation

Operation Manual 29

To Prepare a Capillary Column for Installation

Materials needed

• Capillary column

• Column cutter, ceramic (5181-8836) or diamond (5183-4620)

• Ferrules

• 0.27 mm id, for 0.10 mm id columns (5062-3518)

• 0.37 mm id, for 0.20 mm id columns (5062-3516)

• 0.40 mm id, for 0.25 mm id columns (5181-3323)

• 0.5 mm id, for 0.32 mm id columns (5062-3514)

• 0.8 mm id, for 0.53 mm id columns (5062-3512)

• Gloves, clean

• Large (8650-0030)

• Small (8650-0029)

• Inlet column nut (5181-8830 for Agilent 7890A)

• Loupe

• Septum (may be old, used inlet septum)

Procedure

WARNING

The GC operates at high temperatures. In order to avoid burns, do not

touch any parts of the GC until you are sure they are cool.

CAUTION

Always wear clean gloves while handling any parts that go inside the

GC or analyzer chambers.
