50 Operation Manual

3 Operating in Electron Impact (EI) Mode

Venting the MS

A program in the data system automates the venting process. It

turns off the GC and MS heaters and the turbo pump at the

correct time.

The MS will be damaged by incorrect venting. A turbo pump will

be damaged if it is vented while spinning at more than 50% of its

normal operating speed.

WARNING

The use of hydrogen gas is specifically prohibited with this product.

CAUTION

Never vent the MS by allowing air in through either end of the foreline

hose. Use the vent valve or remove the column nut and column.

Do not exceed the maximum recommended total gas flow. See Table 2.
