Operating in Chemical Ionization (CI) Mode 4

Operating the CI MS

Operation Manual 75

Operating the CI MS

Operating your GC/MS in the CI mode is slightly more

complicated than operating in the EI mode. After tuning, gas

flow, temperatures (Table 5), and electron energy may need to

be optimized for your specific analyte.

Start the system in CI mode

When starting up the system you may begin in either PCI or NCI

mode. Depending upon the application, use the following

reagent gas flowrates during system startup:

• PCI mode set reagent gas flow to 20 (1 mL/min)

• NCI mode set reagent gas flow to 40 (2 mL/min)

Table 5 Temperatures for CI operation

Ion source Analyzer GC/MS interface

PCI 300 °C 150 °C 280 °C

NCI 150 °C 150 °C 280 °C
