32 Operation Manual
2 Installing GC Columns
To Install a Capillary Column in a Split/Splitless Inlet
Figure 3 Installing a capillary column for a split/splitless inlet
Insulation cup
Reducing nut
Capillary column
Ferrule (inside nut)
Inlet column nut
Septum
4 to 6 mm
