Agilent Technologies 7200 - Page 46

46 Operation Manual
3 Operating in Electron Impact (EI) Mode
The GC/MS Interface
Figure 10 The GC/MS interface
Column end protrudes 1 to 2 mm into the ionization chamber.
IRM calibrant in
MS GC oven
Spring-loaded tip
seal entrance to
ion source
Column not shown
Heater sensor assembly
Column nut
