110 Agilent 8453 Dissolution Testing System Installing and Operating Manual
4 Using the Valve Unit and Valve-pump Controller
Servicing Your Valve System
Cables and Connectors
Tab le 30 Controller-to-Valve Cable (5062-2407)
Pin
Valve-pump Controller
Pin
Valve Unit
1, 2 GND
3, 4 + 5 V
7,8 24 V AC
9Encoder Bit 0
10 Encoder Bit 1
11 Encoder Bit 2
12 Position
13 Run(-)
*
* (-) means active low.
14, 15 24 V AC
Tab le 31 GPIO-to-controller Cable (G1103-61610)
Pin
Spectrophotometer
Pin
Valve-pump Controller
10 1 GND
22A0
33A1
44A2
55D0IN
66D1IN
77D2IN
88R/W(-)
*
99DV(-)
†
