58 Agilent 8453 Dissolution Testing System Installing and Operating Manual
2Setting Up
Installing Your Multibath System
4 Replace the fuse holder.
5 Close the socket cover.
Setting Up Your Valve Units
Place the valve units on a bench, allowing adequate space at rear for access to
connectors. Each valve unit is identified by a 10-digit serial number on a label
attached to the rear panel. Write the serial numbers of the valve units here:
1.)__________________________________________________________________
2.)__________________________________________________________________
3.)__________________________________________________________________
4.)__________________________________________________________________
Figure 22 Front View of Valve Unit
Channel display
Status lamp
Valve drive assembly
Valve
