Agilent 8453 Dissolution Testing System Installing and Operating Manual 15
Site Requirements and Specifications 1
Specifications
Specifications
Peristaltic Pumps 1VS and 8VS
The peristaltic pumps 1VS and 8VS are for one and eight pumping channels.
The pumps are designed for liquid samples. Due to the peristaltic pump
principle only the tubing is in contact with the liquid.
The pumps can be operated manually and remotely via a digital interface. If
used for automated sampling in the dissolution testing application, only the
remote operation is applied.
Connect the pump 1VS to the valve-pump-controller only by the controller-to-pump cable
(PN G1103-61612) provided by Agilent.
Connect the pump 8VS to the 8453 spectrophotometer only by the GPIO-to-pump cable
(PN G1103-61607) provided by Agilent
Tab le 1 Physical Specifications Peristaltic Pumps 1VS and 8VS
Type Specification Comments
Dimensions 15.9 cm (6.2 inches) wide
19.3 cm (7.6 inches) deep
11.2 cm (4.4 inches) high
15.9 cm (6.2 inches) wide
26.5 cm (10.5 inches) deep
11.2 cm (4.4 inches) high
Pump 1VS
Pump 8VS
Weight 3.25 kg (7.2 lbs)
3.3 kg (7.3 lbs)
Pump 1VS
Pump 8VS
Line voltage 100–120 V AC ± 10%
220–240 V AC ± 10%
Select 115 V AC
Select 230 V AC
Line frequency 50–60 Hz
Power consumption 55 VA Maximum
Ambient operating temperature 5–40 °C (41–104 °F)
