16 Agilent 8453 Dissolution Testing System Installing and Operating Manual
1 Site Requirements and Specifications
Specifications
Ambient non-operating temperature -40–70 °C (-4–158 °F)
Humidity <90%, at 25–40 °C (77–104 °F) Non-condensing
Operating altitude Up to 2000 m (6,500 ft)
Non-operating altitude Up to 4600 m (14,950 ft) For storing the
instrument
Safety standards: IEC, CSA, UL Installation Category II, Pollution
Degree 2
For indoor use only
Tab le 2 Performance Specifications Peristaltic Pumps 1VS and 8VS
Type Specification Comments
Flow rate 2 - 14 ml/min Pump tubing with 2.06 mm inner diameter
Speed 1 - 67 rpm clock wise and counter clockwise operation
Pumping pressure < 2 bar (30 psi)
Pumping distance < 7 m
Tab le 1 Physical Specifications (continued)Peristaltic Pumps 1VS and 8VS
Type Specification Comments
