42 Agilent 8453 Dissolution Testing System Installing and Operating Manual
2Setting Up
Installing a Valve-based Sampling System
Setting Up Your Valve Unit
Place the valve unit on a bench, allowing adequate space at rear for access to
connectors. Each valve unit is identified by a 10-digit serial number on a label
attached to the rear panel. Write the serial number of the valve unit here:
_____________________________________________________________________
Figure 12 Front View of Valve Unit
Status lamp
Valve drive assembly
Valve
Channel display
