Agilent 8453 Dissolution Testing System Installing and Operating Manual 59
Setting Up 2
Installing Your Multibath System
This safety symbol on the front of the valve unit indicates you should refer to
the following information.
Figure 23 Rear View of Valve Unit
Manual advance
button
Remote/manual
switch
After prolonged use the valve may become contaminated with particulate matter,
causing leaks between the rotor and stator. Leaks will appear at the recess on the
underside of the valve. Do not place the valve unit above ventilation slits of other
electrical appliances. If you are using flammable or toxic solvents, place the valve
unit in a safe container.
