7-45
Adjustments
Agilent Service Support Software
The following table is an example of the calibration information that is
required to ensure accuracy to measurements using the power sensor.
This window is accessed for data entry by selecting the words CAL
DATA from the Calibration Type field in the Edit or New Test
Equipment window.
NOTE The serial number of the test equipment added will be displayed in the
Equipment field of the Test Equipment dialog box (13).
Removing Test Equipment
Removal of test equipment is accomplished using the Test Equipment dialog box.
Example Calibration Data
Frequency
(MHz)
Calibration
Factor (%)
0.100 97.6
03000 98.9
1.0 99.1
3.0 99.4
