Agilent Technologies 8719ET Service Guide

Service Guide 4-21
8719ET/20ET/22ET Start Troubleshooting Here
8719ES/20ES/22ES Receiver Check
RF Network Analyzers
Receiver Check
Check the frequency response for the R, A, and B channels of the analyzer. If any input
shows unexpected results, go to Chapter 8 , “Receiver Troubleshooting.”
Table 4-3 Frequency Response (Characteristic)
Model Type Channel Frequency Band Frequency Response
(Characteristic)
ES R
0.05 − 20.05 GHz ±1.5 dB
20.05 − 32.00 GHz ±2.5 dB
32.00 − 40.05 GHz +2.5 dB, −6.0 dB
A and B
0.05 −.500 GHz +2.5 dB, −28 dB
0.5 − 20.05 GHz ±2.5 dB
20.05 − 32.00 GHz ±3.0 dB
32.00 − 40.05 GHz +3.0 dB, −6.0 dB
ET R
0.05 − 20.05 GHz ±1.5 dB
20.05 − 32.00 GHz ±2.5 dB
32.00 − 40.05 GHz +2.5 dB, −6.0 dB
B
0.05 − 20.05 GHz ±2.5 dB
20.05 − 32.00 GHz ±3.0 dB
32.00 − 40.05 GHz +3.0 dB, −6.0 dB
