5-10 Service Guide
Power Supply Troubleshooting 8719ET/20ET/22ET
If the Red LED of the Preregulator (A15) Is On 8719ES/20ES/22ES
RF Network Analyzers
Verify the Preregulator (A15)
Verify that the preregulator (A15) is supplying the correct voltages to the post regulator
(A8). Use a voltmeter with a small probe to measure the output voltages of A15W1’s plug.
Refer to Table 5-2 and Figure 5-6.
• If the voltages are not within tolerance, replace A15.
• If the voltages are within tolerance, A15 is verified. Go to “Check for a Faulty Assembly”
on page 5-11.
Table 5-2 Output Voltages
Pin A15W1P1
(Disconnected)
Voltages
A8J2
(Connected)
Voltages
A15
Preregulator
Mnemonic
1 N/C N/C N/C
2 +100 to +125 +100 to +125 (not used)
3,4 +22.4 to +33.6 +17.0 to +18.4 +18 V
5,6 −22.4 to −33.6 −17.0 to −18.4 −18 V
7 N/C +7.4 to +8.0 N/C
8 +9.4 to +14 +7.4 to +8.0 +8 V
9,10 −9.4 to −14 −6.7 to −7.3 −8 V
11 +32 to +48 +24.6 to +26.6 +25 V
12 N/C +24.6 to +26.6 N/C
NOTE: The +5 VD supply must be loaded by one or more assemblies at
all times, or the other voltages will not be correct. It connects to the
motherboard connector A17J3 Pin 4.
