Agilent Technologies 8719ET Service Guide

13-72 Service Guide
Replaceable Parts 8719ET/20ET/22ET
Replaceable Part Listings 8719ES/20ES/22ES
RF Network Analyzers
Front Panel Assembly, Inside
Ref.
Desig.
Models Options HP/Agilent Part
Number
Qty Description
1 All All 08753-00150 1 Display Hold Down
2 All All 2090-0386 1 Display Lamp
3 All All 08720-0094 4 Display Glass Clips
4 All All 1000-0995 1 Display Glass
5 All All 08720-00096 2 Gasket
6 All All 2190-0067 1 Washer Lk .256
2950-0006 1 Nut Hex 1/4-32
1510-0038 1 Ground Post
7 All ES STD,089 08720-60305 1 Front Panel Frame
(without nameplate)
7 All ES 012 08720-60306 1 Front Panel Frame
(without nameplate)
7 All ES 085 08720-60307 1 Front Panel Frame
(without nameplate)
7 All ES 012 + 085 08720-60308 1 Front Panel Frame
(without nameplate)
8 All All E4400-40003 1 RPG Knob (Front Round Knob)
9 All All 1990-1864 1 RPG (Includes Cable And
Hardware)
10 All All 08720-40016 1 Flubber Keypad
11 All All 0515-0430 9 Screw Sm 3.0 6 Cwpntx
12 All All 0515-0665 4 Screw Smm 3.0 14 Cwpntx
13 All All 0515-0372 3 Screw Smm 3.0 8 Cwpntx
14 All All 1400-1439 2 Cable-Clips Inverter Cable
15 All All 08753-20948 1 Cover for Inverter
16 All All 8120-8842 1 Ribbon Cable (5R) A2 to A20
17 All All 08720-60074 1 Ribbon Cable (50R) A2 to A17
18 All All 1 Ribbon Cable (50R) A2 to GSP
19 All All 8120-8409 1 Ribbon Cable (31R) A2 to A18
20 All All 8120-8439 1 Ribbon Cable (31R) A2 to A1
21 8719ES All 08719-80038 1 Nameplate, 8719ES
21 8719ET All 08719-80035 1 Nameplate, 8719ET
