13-78 Service Guide
Replaceable Parts 8719ET/20ET/22ET
Replaceable Part Listings 8719ES/20ES/22ES
RF Network Analyzers
Hardware, Top
Ref. Desig. Models Option HP/Agilent Part
Number
Qty Description
1 All All 08720-40004 3 Locator Hold Downs
2 All All 08720-00066 1 Can Hold Down
3 All All 0515-2035 1 Screw SMM 3.0 16 PCFLTX
4 All All 08753-20062 1 PC Stabilizer Cap
5 All All 08720-40011 1 PC Board Stabilizer
6 All All 0515-2086 16 Screw SMM 4.0 7 PCFLTX
7 All All 0515-0458 4 Screw SMM 3.5 10 CWPNTX
8 All All 0515-0431 2 Screw SMM 3.5 6 CWPNTX
9 All All 0515-0430 3 Screw SMM 3.0 6 CWPNTX
10 All All 08720-00023 1 Source Hold Down
11 All All 0515-0377 2 Screw SMM 3.5 10 CWPNTX
12 All All 08720-00038 1 Source Cover
13 All All 0515-1400 3 Screw SMM 3.5 8 PCFLTX
14 All All 08720-20185 1 Source Casting
