13-64 Service Guide
Replaceable Parts 8719ET/20ET/22ET
Replaceable Part Listings 8719ES/20ES/22ES
RF Network Analyzers
Front RF Assemblies
Ref.
Desig.
Agilent Models Options HP/Agilent Part
Number
Qty Description
1 8719ET
8720ET
All 5064-3949 1 Test Port Connector
1 8722ET All 5064-3950 1 Test Port Connector
A19 All All 08720-60261 1 GSP Board
A22 All All 08720-60152 1 Display Interface Board
A27 8719ET/ES
8720ET/ES
All 8493C Opt. 010 1 Attenuator
A27 8722ET/ES All 8490C Opt. 010 1 Attenuator
A56 All ES Models All 08720-60182 1 LED Board
A62 8719ET/ES
8720ET/ES
All 5086-7968 1 RF Coupler
A62 8719ET/ES
8720ET/ES
All 5086-6968 1 RF Coupler
(Rebuilt-Exchange)
A62 8722ET/ES All 5086-7518 1 RF Coupler
A62 8722ET/ES All 5086-6518 1 RF Coupler
(Rebuilt-Exchange)
A63 8719ES
8720ES
All 5086-7968 1 RF Coupler
A63 8719ES
8720ES
All 5086-6968 1 RF Coupler
(Rebuilt-Exchange)
A63 8722ES All 5086-7518 1 RF Coupler
A63 8722ES All 5086-6518 1 RF Coupler
(Rebuilt-Exchange)
A72 All ES Models All 5087-7115 1 R Channel Buffer
Amplifier
A72 All ES Models All 5087-6115 1 R Channel Buffer Amp.
(Rebuilt-Exchange)
A73 All ES Models 400 5087-7115 1 R Channel Buffer
Amplifier
A73 All ES Models 400 5087-6115 1 R Channel Buffer Amp.
(Rebuilt-Exchange)
A75 8722ES Non Opt. 400
Non Opt. 089
Non Opt. 085
8490D OPT 006 1 Attenuator 6 dB
A75 8722ES 089
085
8490D OPT 003 1 Attenuator 3 dB
A75 8722ES 400 8490D OPT 010 1 Attenuator 10 dB
A76 8722ES 400 8490D OPT 010 1 Attenuator 10 dB
W99 All All 8120-6890 1 Ribbon Cable
