Replaceable Parts 8719ET/20ET/22ET
Replaceable Part Listings 8719ES/20ES/22ES
RF Network Analyzers
Front Cables, All Models
Ref.
Desig.
Agilent Models Options Type HP/ Part
Number
Qty Description
W18 8719ES
8720ES
085,089 SR 08720-20105 1 Front Panel
R- Channel In to A24
W18 8722ES 085,089 SR 08722-20058 1 Front Panel
R-Channel In to A24
W20 8719ES
8720ES
8722ES
085,089 SR 08720-20281 1 A24 to A64
W23 8719ES Standard
007,012
SR 08720-20047 1 A58 to Front Panel
R Channel Out
W23 8722ES Standard
007,012
SR 08722-20071 1 A58 to Front Panel R
Channel Out
W30 8719ET
8720ET
8722ET
All SR 08720-20026 1 A62 to A65
W32 8719ET
8720ET
004 SR 08720-20021 1 A58 to A69
W32 8722ET 004 SR 08722-20069 1 A58 to A69
W33 8719ES
8720ES
Standard
007,012,400
SR 08720-20311 1 Front Panel R
Channel In To A72
W33 8722ES Standard
007,012,400
SR 08722-20075 1 Front Panel R
Channel In To A75
W36 8719ES
8720ES
Standard
007,012,400
SR 08720-20312 1 A72 To A64
W36 8722ES Standard
007,012,400
SR 08720-20041 1 A72 To A64
W38 8719ES
8720ES
085,089 SR 08720-20313 1 A58 to A72
W38 8722ES 085,089 SR 08722-20130 1 A58 to A75
W41 8719ES
8720ES
400 SR 08720-20316 1 A74 to A73
W41 8722ES 400 SR 08722-20936 1 A74 to A76
W50 8719ES
8720ES
8722ES
085,089 SR 08720-20314 1 A72 to A23
W53 8719ES
8720ES
400+089 SR 08720-20281 1 A24 to A64
