Agilent Technologies 8719ET - Hardware, Front

13-82 Service Guide
Replaceable Parts 8719ET/20ET/22ET
Replaceable Part Listings 8719ES/20ES/22ES
RF Network Analyzers
Hardware, Front
Illustration Hardware, Front
Ref.
Desig.
Agilent Models Option HP/Agilent
Part Number
Qty Description
1 All All 0515-0382 3 Screw SMM 4.0 12 CWPNTX
2 All All 08753-00152 1 Disk Drive Bracket
2 All All 0505-1934 4 Screw SMM 2.5 6 CWPNTX
3 All All 08720-00077 1 Actuator Switch Arm
3 All All 08753-40015 1 AC Line Button
4 All All 0515-0430 2 Screw SMM 3.0 6 CWPNTX
5 All All 0515-2086 6 Screw SMM 4.0 7 PCFLTX
6 All All 0515-1400 1 Screw Smm 3.5 8 Pcfltx
7 All All 08720-00093 1 Cable Mounting Bracket
8 All All 5022-1087 2 Nut-Flange
9 8719ET
8720ET
All 5064-3949 1 Test Port Connector
Replacement Kit
9 8722ET All 5064-3950 1 Test Port Connector
Replacement Kit
10 All All 0515-0430 3 Screw SMM 3.0 6
