2-42 Service Guide
System Verification and Performance Tests 8719ET/20ET/22ET
Performance Tests 8719ES/20ES/22ES
RF Network Analyzers
Dynamic Range Performance Test
This test checks the dynamic range of the analyzer.
Analyzer warmup time: 30 minutes.
Entering Frequency Points
1. Press .
2. To enter the values for the first frequency segment and power value, press the
following:
Enter the power level from Table 2-12 and press .
Table 2-11 Required Equipment
Equipment Description 8719ET/ES and 8720ET/ES 8722ET/ES
HP/Agilent Calibration Kit 85052B 85056A
HP
/Agilent RF Cable Set 85131F 85133F
Table 2-12 Power Levels for the Frequency Segment Values
Model
Power
dBm
ES Models
8719ES and 8720ES 5
8719ES and 8720ES Option 007 10
8722ES (50MHz to 20 GHz) −5
(20.0 GHz to 40.05 GHz) −10
8722ES Option 007 (50MHz to 20 GHz) 0
(20.0 GHz to 40.05 GHz) −5
ET Models
8719ET and 8720ET 5
8722ET (50MHz to 20 GHz) 0
(20.0 GHz to 40.05 GHz) −5
Preset
Preset
Start 50 M/µ
Stop 50.000101 M/µ
11 x1
x1 Return
