Agilent Technologies 8719ET Service Guide

Service Guide 13-87
8719ET/20ET/22ET Replaceable Parts
8719ES/20ES/22ES Replaceable Part Listings
RF Network Analyzers
Miscellaneous Part Numbers
Description HP/Agilent
Part Number
Service Tools
TOOL KIT for All Models -- includes the following: 08722-60018
Adapter 2.4-mm (F) APC 3.5 (F) 11901B
Adapter 2.4-mm (F) APC 3.5 (M) 11901D
Extender Board Assembly-for 2nd Converters 08415-60019
Extender Board Assembly 08753-60155
Source Control Extender Board Assembly 08720-60151
Adapter-SMB (M) TO SMB (M) 1250-0669
Adapter-SMB (M) TO BNC (F) 1250-1237
Adapter-SMA (F) TO SMA (F) 1250-1158
Adapter-SMA (M) TO SMA (M) 1250-1159
SMB Tee 1250-1391
Fuse .5A 125 V 2110-0046
Fuse 1A 125 V 2110-0047
Fuse 2A 125 V 2110-0425
Fuse 4A 125 V 2110-0476
Fuse 3.15A 250 V 2110-0655
Cable Assembly-Extender RF 5061-1022
Cable Assembly-SMA Flex 8120-4396
Wrench-Open Ended 5.5 8710-1770
Bag-antistatic 12.0 X 15.0D 9222-1132
Cable Second Converter/IF 8120-5040
Documentation
Agilent Technologies 8719ET/ES, 8720ET/ES, 8722ET/ES Manual Set on
CD-ROM -- includes all manuals listed in the manual set
08720-90418
8719ET/ES, 8720ET/ES, 8722ET/ES Manual Set -- includes the following
manuals:
08720-90390
Installation and Quick Start Guide 08720-90391
User’s Guide 08720-90392
Reference Guide 08720-90393
Programmer’s Guide 08753-90475
8719ET/ES, 8720ET/ES, 8722ET/ES Service Guide -- includes the following: 08720-90397
8719ET/ES, 8720ET/ES, 8722ET/ES Service Guide on CD-ROM 08720-90419
