Service Guide 2-33
8719ET/20ET/22ET System Verification and Performance Tests
8719ES/20ES/22ES Performance Tests
RF Network Analyzers
Performance Tests
The performance tests verify that the analyzer meets its published specifications. Data
from these tests should be recorded on the “Performance Test Record,” beginning on
page 2-46.
This section includes the following performance tests:
• Frequency Accuracy Performance Test, on page 2-34.
• Level Accuracy Performance Test, on page 2-36.
• Source Linearity Performance Test, on page 2-38.
• Dynamic Range Performance Test, on page 2-42.
