13-14 Service Guide
Replaceable Parts 8719ET/20ET/22ET
Replaceable Part Listings 8719ES/20ES/22ES
RF Network Analyzers
Bottom Assemblies and Cables for 8719ES and 8720ES
Options 012, 012+007
Ref. Desig. Options HP/Agilent
Part Number
Qty
Description
A7 08720-60253 1 CPU Repair Kit
A7 08720-69253 1 CPU Repair Kit (Rebuilt-Exchange)
A17 08720-60264 1 Motherboard
A51 08720-60274 1 Bd Assy-Test Set Interface
A52 5086-7456 1 Assy-Pulse Generator
A52 5086-6456 1 Assy-Pulse Generator (Rebuilt-Exchange)
A60,A61 5086-7458 2 Bias Tee
A60,A61 5086-6458 2 Bias Tee (Rebuilt-Exchange)
A64,A65,A66 5086-7614 3 Assy-Sampler
A64,A65,A66 5086-6614 3 Assy-Sampler (Rebuilt-Exchange)
A69 33321-60050 1 Attenuator 0-55 dB
A74 012+007 08720-60006 1 Transfer Switch
A74 012 5086-7642 1 Transfer Switch
A74 012 5086-6642 1 Transfer Switch (Rebuilt-Exchange)
A98 08720-60121 1 Frequency Converter
A98 08720-69121 1 Frequency Converter (Rebuilt-Exchange)
W14 08720-20154 1 A63 to Front Panel B-Out
W15 08720-20058 1 Front Panel B-In to A66
W16 08720-20104 1 Front Panel A-In to A65
W17 08720-20164 1 A62 to Front Panel A-Out
W25 012+007 08720-20249 1 A61 to A62
W25 012 08720-20259 1 A61 to A62
W26 08720-20025 1 A60 to A63
W27 08720-20011 1 A74 to A60
W28 08720-20248 1 A74 to A61
W29 08720-20009 1 A69 to A74
W32 08720-20021 1 A58 to A69
W36 08720-20312 1 A72 to A64
W52 08720-20098 3 External Link
