13-20 Service Guide
Replaceable Parts 8719ET/20ET/22ET
Replaceable Part Listings 8719ES/20ES/22ES
RF Network Analyzers
Bottom Assemblies and Cables for 8719ES and 8720ES
Options 085, 085+089
Ref. Desig. Options HP/Agilent
Part Number
Qty
Description
A7 08720-60253 1 CPU Repair Kit
A7 08720-69253 1 CPU Repair Kit (Rebuilt-Exchange)
A17 08720-60264 1 Motherboard
A23,A24 5086-7589 1 R-channel Switches
A23,A24 5086-6589 2 R-channel Switches (Rebuilt-Exchange)
A51 08720-60274 1 Bd Assy-Test Set Interface
A52 5086-7456 1 Assy-Pulse Generator
A52 5086-6456 1 Assy-Pulse Generator (Rebuilt-Exchange)
A64,A65,A66 5086-7614 3 Assy-Sampler
A64,A65,A66 5086-6614 3 Assy-Sampler (Rebuilt-Exchange)
A69,A70,A71 33326-60006 3 Attenuator 0-55 dB
A74 33311J 1 Transfer Switch
A98 08720-60121 1 Frequency Converter
A98 08720-69121 1 Frequency Converter (Rebuilt-Exchange)
W14 08720-20154 1 A63 to Front Panel B-Out
W17 08720-20164 1 A62 to Front Panel A-Out
W20 08720-20281 1 A24 to A64
W32 08720-20146 1 A58 to A69
W50 08720-20314 1 A72 to A23
W51 08720-20279 1 A23 to A24
W52 08720-20098 6 External Link
W54 08720-20282 1 A23 to Front Panel R-Channel Out
W58 08720-20135 1 A69 to Rear Panel Source Out
W59 08720-20144 1 Rear Panel Source to A74
W60 08720-20161 1 A74 to Front Panel A-Switch
W61 08720-20159 1 A74 to Front Panel B-Switch
W65 08720-20158 1 A70 to A65
W66 08720-20157 1 A71 to A76
W68 08720-20165 1 Front Panel B-In to A71
W69 08720-20166 1 Front Panel A-In to A70
