13-26 Service Guide
Replaceable Parts 8719ET/20ET/22ET
Replaceable Part Listings 8719ES/20ES/22ES
RF Network Analyzers
Bottom Assemblies and Cables for 8719ES and 8720ES
Option 400+089
Ref. Desig. Options HP/Agilent
Part Number
Qty
Description
A7 08720-60253 1 CPU Repair Kit
A7 08720-69253 1 CPU Repair Kit (Rebuilt-Exchange)
A17 08720-60264 1 Motherboard
A23, A24 5086-7589 2 R-Channel Switch
A23,A24 5086-6589 2 R-channel Switches (Rebuilt-Exchange)
A51 400 08720-60275 1 Bd Assy-Test Set Interface
A52 5086-7456 1 Assy-Pulse Generator
A52 5086-6456 1 Assy-Pulse Generator (Rebuilt-Exchange)
A60,A61 5086-7458 2 Bias Tee
A60,A61 5086-6458 2 Bias Tee (Rebuilt-Exchange)
A64,A65,
A66,A67
5086-7614 4 Assy-Sampler
A64,A65,
A66,A67
5086-6614 4 Assy-Sampler (Rebuilt-Exchange)
A70,A71 33326-60006 2 Attenuator 0-55 dB
A74 5086-7975 1 Switch Splitter
A74 5086-6975 1 Switch Splitter (Rebuilt-Exchange)
A99 08720-60124 1 Frequency Converter
A99 08720-69124 1 Frequency Converter (Rebuilt-Exchange)
W18 08720-20105 1 Front Panel R-Channel IN to A24
W22 08720-20033 1 A63 to A66
W25 08720-20259 1 A61 to A62
W26 08720-20025 1 A60 to A63
W30 08720-20026 1 A62 to A65
W32 08720-20173 1 A58 to A69
W37 08720-20136 1 A71 to A60
W38 08720-20145 1 A70 to A61
W39 08720-20169 1 A74 to A70
W40 08720-20168 1 A74 to A71
W41 08720-20316 1 A74 to A73
W50 08720-20314 1 A72 to A23
W52 08720-20098 1 External Links
