Agilent Technologies 8719ET Service Guide

13-52 Service Guide
Replaceable Parts 8719ET/20ET/22ET
Replaceable Part Listings 8719ES/20ES/22ES
RF Network Analyzers
Bottom Assemblies and Cables for 8722ES Option 400+089
Ref.
Desig.
Options HP/Agilent
Part Number
Qty
Description
A7 08720-60253 1 CPU Repair Kit
A7 08720-69253 1 CPU Repair Kit (Rebuilt-Exchange)
A17 08720-60264 1 Motherboard
A23,A24 5086-7679 2 R-channel Switches
A23,A24 5086-6589 2 R-channel Switches (Rebuilt-Exchange)
A51 08720-60274 1 Bd Assy-Test Set Interface
A52 5086-7456 1 Assy-Pulse Generator
A52 5086-6456 1 Assy-Pulse Generator (Rebuilt-Exchange)
A60,A61 5086-7484 2 Bias Tee
A60,A61 5086-6484 2 Bias Tee (Rebuilt-Exchange)
A64,A65,
A66,A67
5086-7614 4 Assy-Sampler
A64,A65,
A66,A67
5086-6614 4 Assy-Sampler (Rebuilt-Exchange)
A70,A71 33326-60006 2 Attenuator 0-55 dB
A74 5087-7002 1 Switch Splitter
A74 5087-6002 1 Switch Splitter (Rebuilt-Exchange)
A75 08490D#003 1 Fixed Attenuator (3 dB)
A99 08720-60124 1 Frequency Converter
A99 08720-69124 Frequency Converter (Rebuilt-Exchange)
W25 08722-20056 1 A61 to A62
W26 08722-20057 1 A60 to A63
W32 08722-20054 1 A58 to A74
W37 08722-20059 1 A71 to A60
W38 08722-20061 1 A70 to A61
W39 08722-20063 1 A74 to A70
W40 08722-20062 1 A74 to A71
W41 08722-20936 1 A74 to A76
W51 08720-20279 1 A23 to A24
W52 08722-20024 1 External Link
W56 08722-20135 1 A74 to A75
