2-18 Service Guide
System Verification and Performance Tests 8719ET/20ET/22ET
System Verification 8719ES/20ES/22ES
RF Network Analyzers
Required Equipment and Accessories
The following equipment and accessories are required to verify the network analyzer
system. (For information on compatible printers, refer to the user’s guide).
• HP Printer
• Centronics or GPIB Interface Cable
• Verification Kit
• Calibration Kit
• RF Cable Set
Analyzer warmup time: 30 minutes
Table 2-1 8719ET/ES and 8720ET/ES Supported System Configurations
Description 3.5 mm 7 mm Type-N
Calibration Kit 85052B/C/D 85050B/C/D 85054B/D
Verification Kit 85053B 85051B 85055A
Cables 85131C/D/E/F 85132C/D/E/F 85131C/D/E/F 3.5 mm85130C
(3.5 mm to Type-N adaptor set)
Table 2-2 8722ET/ES Supported System Configurations
Description 2.4 mm 3.5 mm
Calibration Kit 85056A/D 85052B/C/D
Verification Kit 85057B 85053B
Cables 85133C/D/E/F 85131C/D/E/F
