Agilent Technologies 8719ET Service Guide

2-50 Service Guide
System Verification and Performance Tests 8719ET/20ET/22ET
Performance Test Record 8719ES/20ES/22ES
RF Network Analyzers
Dynamic Range
Model Type and Frequency Range Specification Results Measurement
Uncertainty
Not Option 007 Option 007 S21 /
Transmission
8719ET and 8720ET
50 MHz to 840 MHz 102 dB
N/A
____________
±0.29 dB
840 MHz to 20.05 GHz 104 dB
N/A
____________
±0.29 dB
8719ES and 8720ES
50 MHz to 840 MHz 77 dB
82
____________
±0.29 dB
840 MHz to 20.05 GHz 100 dB
105
____________
±0.29 dB
8722ET
50 MHz to 840 MHz 98 dB
N/A
____________
±0.29 dB
840 MHz to 8 GHz 102 dB
N/A
____________
±0.29 dB
8 GHz to 20 GHz 100 dB
N/A
____________
±0.29 dB
20 GHz to 40.05 GHz 89 dB N/A ____________
±0.29 dB
8722ES
50 MHz to 840 MHz 67 dB 72 dB ____________
±0.29 dB
840 MHz to 8 GHz 93 dB 98 dB ____________
±0.29 dB
8 GHz to 20 GHz 91 dB 96 dB ____________
±0.29 dB
20 GHz to 40.05 GHz
80 dB
a
85 dB
a
____________
±0.29 dB
a
For Option 085 or Option 012, subtract 3 dB.
