6-28
Calibrating for Increased Measurement Accuracy
One-Port Reflection Error Correction
13. To compute the error coefficients, press: .
The analyzer displays the corrected data trace. The analyzer also shows the notation Cor to the left of
the screen, indicating that the correction is switched on for this channel.
NOTE The open, short, and load could be measured in any order, and need not follow the order in
this example.
NOTE You can save or store the error correction to use for later measurements. Refer to Chapter 4 ,
“Printing, Plotting, and Saving Measurement Results” for procedures.
14. This completes the one-port correction for reflection measurements. You can connect and measure your
device under test.
