Agilent Technologies E4448A Service Guide

236 Chapter 10
Replaceable Parts Lists and Locations
Replaceable Parts
Table 10-3 Cables
a
Description Part
Number
E4440A E4443A E4445A E4446A E4447A E4448A
W1 Cable (5), coax, Front
Panel External Trigger to
A8 Analog IF Assy. P1
E4406-60139 X X X X X X
W2 Cable, ribbon 100 pin,
Front Panel
E4440-60075 X X X X X X
W5 Cable Flat flex,
Front Panel Interface to flat
panel display
(for serial prefix
below US/MY/SG 4611)
8120-8480 X X X X X X
W5 Cable Flat flex,
Front Panel Interface to
display converter board
(for serial prefix
US/MY/SG 4611
and above)
8121-1419 X X X X X X
W6 Cable flat flex,
Disk drive to Motherboard
8120-8461 X X X X X X
W7 Cable, semi-rigid
(with ferrites),
For standard “N” type RF
Input to A14 Attenuator
E4440-20067 X X X
W7 Cable, semi-rigid,
For Option BAB 3.5 APC RF
Input to A14 Attenuator
E4440-20099 X
W7 Cable, semi-rigid,
For standard 2.4mm RF
Input to A14 Attenuator
E4446-20020 X X X
W8 Cable, semi-rigid
(with ferrites),
A14 attenuator to
A15 attenuator
E4440-20068 X X X
E4446-20021 X X X
W9 Cable, semi-rigid, A15
Attenuator to A19 RYTHM
E4440-20069 X X X
W10 Cable (8), coax, 7.5
MHz from A8 Analog IF P2,
to A7 Digital IF, P1
8120-5022 X X X X X X
